P6 ( 768mm x 768mm )
P6 ( 768mm x 768mm )
| Pixel Pitch (in mm) | 6 |
| Pixel Density (Dots/cabinet) | 1684 |
| Module Size (mm*mm) | 192*192 |
| Module Resolution (pixels) | 32*32 |
| Pixel Identification | SMD3535 |
| Driving IC | MBI5124GP |
| Scan Mode | 8 |
| Brightness (cd/m2 | 6000-7000 |
| Refresh Rate (Hz) | ≥1200 |
| Power Supply | 5V-60A |
| Power Consumption (Watt) | 400 |
| Cabinet Resolution | 128*128 |
| Cabinet Average Power Consumption (Unit/hr) | 0.4 |
| Cabinet Size (mm*mm) | 768*768 |
| Cabinet Weight (Kg) | 19.60 |
| Cabinet Material | Die Cast |
