P4 ( 576mm x 576mm )
P4 ( 576mm x 576mm )
| Pixel Pitch (in mm) | 4 |
| Pixel Density (Dots/cabinet) | 20736 |
| Module Size (mm*mm) | 192*192 |
| Module Resolution (pixels) | 48*48 |
| Pixel Identification | SMD1921 |
| Driving IC | MBI5124GP |
| Scan Mode | 16 |
| Brightness (cd/m2 | 5000-6000 |
| Refresh Rate (Hz) | 4800 |
| Power Supply | 5V-60A |
| Power Consumption (Watt) | 300 |
| Cabinet Resolution | 144*144 |
| Cabinet Average Power Consumption (Unit/hr) | 0.3 |
| Cabinet Size (mm*mm) | 576*576 |
| Cabinet Weight (Kg) | 10.18 |
| Cabinet Material | Die Cast |
